| [Standard specifications] |
| Suction type |
| (direct pressure type is seperately available.) |
| Ceremic nozzle: ø 6 mm or larger |
| The most popular general-purpose machine |
| with a foot pedal to turn the machine on and |
| off. The AM-8 or higher grades of products |
| are equipped with a high-performance |
| cyclone seperator. |
|
| |
| |
Cabinet size |
|
| Type |
W |
L |
H |
|
| SAM-6 |
650 x |
500 x |
1560 |
On wheels, integrated dust collector |
| AM-8 |
800 x |
650 x |
1650 |
With integrated dust collector |
| AM-10 |
1000 x |
800 x |
1750 |
With seperate dust collector |
| AM-12 |
1200 x |
1000 x |
1750 |
With seperate dust collector |
| AM-15 |
1500 x |
1200 x |
2000 |
With seperate dust collector |
|
|
|
|
| [Standard specifications] |
| Suction type |
| (direct pressure type is seperately available.) |
| Ceremic nozzle: ø 6 mm or larger |
| The AML type, which has an automatic |
| rotary table, can be automated by setting |
| the vibration (option) and timer (option) |
| for the nozzles. |
| (Select the AMT type if you need a manual |
| rotary tabe.) |
|
| |
| |
Cabinet size |
|
| Type |
W |
L |
H |
Table diameter |
|
| AML-8 |
800 x |
650 x |
1650 |
Minimum ø 500 |
With integrated dust collector |
| AML-10 |
1000 x |
800 x |
1750 |
Minimum ø 700 |
With seperate dust collector |
| AML-12 |
1200 x |
1000 x |
1750 |
Minimum ø 800 |
With seperate dust collector |
| AML-15 |
1500 x |
1200 x |
2000 |
Minimum ø 1000 |
With seperate dust collector |
|
| |
| |
|
|
| [Standard specifications] |
| Suction type |
| (direct pressure type is seperately available.) |
| Ceremic nozzle: ø 6 mm or larger |
| For blasting small works in a lot, this pro- |
| vides low cost and efficiency. This is an |
| automated blasting machine for a given |
| period of time with its timer. Vibration or |
| addition of nozzles is available as an option. |
|
| |
| |
Cabinet size |
|
| Type |
W |
L |
H |
Barrel capacity |
|
| AMP-8 |
800 x |
650 x |
1650 |
4 liters |
With integrated dust collector |
| AMP-10 |
1000 x |
800 x |
1750 |
Minimum 4 liters |
With seperate dust collector |
| AMP-12 |
1200 x |
1000 x |
1750 |
Minimum 5 liters |
With seperate dust collector |
| AMP-15 |
1500 x |
1200 x |
2000 |
Minimum 10 liters |
With seperate dust collector |
|
|
|
|
| [Standard specifications] |
| Suction type |
| (direct pressure type is seperately available.) |
| Ceremic nozzle: ø 6 mm or larger |
| This is suited for blasting heavy products. A |
| swing table type is also available for heavy |
| products. The machine can be an automated |
| by attaching a self-propelled dolly, a timer, |
| and vibration nozzles as options. For some |
| types, a robot operates the nozzles. |
|
| |
| |
Cabinet size |
|
| Type |
W |
L |
H |
Dolly table size |
|
| AMD-8 |
800 x |
800 x |
1840 |
ø 600 |
With integrated dust collector |
| AMD-10 |
1000 x |
1000 x |
2000 |
ø 800 |
With seperate dust collector |
| AMD-12 |
1200 x |
1200 x |
2060 |
ø 1000 |
With seperate dust collector |
| AMD-15 |
1500 x |
1500 x |
2700 |
ø 1200 |
With seperate dust collector |
|
| |
| |
|
|
| [Standard specifications] |
| Suction type |
| (direct pressure type is seperately available.) |
| Ceremic nozzle: ø 6 mm or larger |
| This is more efficient than the barrel type |
| because of the stirring on the tumbling belt |
| while blasting. The approximately 3 to 6 |
| nozzles provide efficient blasting. The |
| equipment can be totally unmanned by |
| attaching an automatic loading/unloading |
| device. The P type has a belt pop-out |
| function in the downward direction during |
| unloading, which fully unloads even round |
| work (patented). The easy unloading is |
| suited for mass production. |
|
| |
| |
Cabinet size |
|
| Type |
W |
L |
H |
Tumbler capacity |
|
| AMTB-OP |
770 x |
670 x |
1510 |
10 liters |
With seperate dust collector |
| AMTB-25 |
700 x |
800 x |
1550 |
25 liters |
With seperate dust collector |
| AMTB-50 |
900 x |
800 x |
1800 |
50 liters |
With seperate dust collector |
| AMTB-100 |
980 x |
840 x |
2000 |
100 liters |
With seperate dust collector |
|
|
|
|
| [Standard specifications] |
| Suction type |
| (direct pressure type is seperately available.) |
| Ceremic nozzle: ø 6 mm or larger |
| The nozzles vibrate as standard and products |
| are blasted from above and below. Air blowing |
| cleans around the exit port. Each nozzle can |
| be additionally attached. The height of the |
| opening can be chagedas customization. |
| | | | | |
| |
| |
|
| |
| Type |
Effective size of work |
Roller pitch |
| AMA-6 |
300mm x 50H |
Pitch: 100mm |
| AMA-8 |
450mm x 75H |
Pitch: 150mm |
| AMA-10 |
600mm x 100H |
Pitch: 150mm |
| AMA-12 |
800mm x 150H |
Pitch: 150mm |
|
| |
| |
|
|
| [Standard specifications] |
| Suction type |
| (direct pressure type is seperately available.) |
| Ceremic nozzle: ø 6 mm or larger |
| Nozzle vibration type |
| Products are blasted from above. |
| Air blowing cleans around exit port. Each |
| nozzle is additionally attached. The height |
| of the opening can be customized. |
|
| |
| Type |
Effective size |
| AMC-6 |
300mm x 50H |
| AMC-8 |
450mm x 75H |
| AMC-10 |
600mm x 100H |
| AMC-12 |
800mm x 150H |
|
|
|
|
| [Standard specifications] |
| Suction type |
| (direct pressure type is seperately available.) |
| Ceremic nozzle: ø 6 mm or larger |
| The nozzles vibrate as standard. There is a |
| chamber only for air blowing around the exit |
| port. The attachment/detachment method for |
| products is selectable from among a robot |
| type. Each single product from such a long |
| products as a roll to a small one is con- |
| tinuously blasted. | | |
| |
|
| |
| Type |
Effective size of work |
| AMI-6 |
ø 50x200H |
| AMI-8 |
ø 100x200H |
| AMI-10 |
ø 200x200H |
| AMI-12 |
ø 250x200H |
| AMI-15 |
ø 300x300H |
| AMI-17 |
ø 350x400H |
|
| |
| |
|
|
| The ATM type, a low cost, |
| workable mid-scale machine, |
| is on wheels and the injection |
| valves require no power |
| supply. The conventional AT |
| types have an on and off |
| mechanism with solenoid |
| valves and a rich lineup from |
| small to large versions. |
| Blasting hoses and nozzles |
| are included as standard. |
|
|
| AT series (Conventional type) |
| Type |
Tank capacity/Effective volume |
| AT-15 |
20/15 liters |
| AT-30 |
40/30 liters |
| AT-50 |
70/50 liters |
| AT-100 |
120/100 liters |
| AT-150 |
210/150 liters |
| AT-220 |
290/220 liters |
| AT-400 |
480/400 liters |
| AT-600 |
710/600 liters |
| AT-800 |
910/800 liters |
|
| |
| ATM series (Air-driven type, On wheels) |
| Type |
Tank capacity/Effective volume |
| ATM-100 |
120/100 liters |
| ATM-150 |
210/170 liters |
|
| |
| |
|
|
|
| [Standard specifications] |
| The standard set includes an injection unit, |
| a one-horsepower compressor, a blasting box |
| (458mm x 358mm x 39mm), filters, abrasive |
| media (WA #120: 2 kg), enjoyable seals, |
| goggles, and a Fruiof knowledge on blasting. |
| This popular, widely used model is applicable |
| for glass working, metal molding, burrs on |
| small work, small-lot production equipment, |
| and a testing machine. |
| | | | | |
| |
|
| |
| Type |
| |
| Petit-blasting PM |
Suction type |
Nozzle: ø 2 mm |
| Petit-blasting PD |
Direct pressure type |
Nozzle: ø 2 mm |
|
| |
| |
| For peening gears and shafts |
| |
|
| Both the air blasting and shot blasting are |
| selectable. Most of these machines are an |
| index type including the self-propelled rotary |
| type for gears. For shafts, coating or roughing |
| of surfaces before painting is also available. |
| Customization to product size is possible |
| based on the stanndard type. The amount |
| and rate of injection can be easily adjusted. |
|
| |
|
|
|
| Sand remaining in an engine block is |
| automatically removed. The sensor detects |
| holes even in different blocks. |
| Nozzles are inserted into the holes in which |
| sand remains with pinpoint accuracy for |
| blasting. For vehicles, various types are |
| available for aluminum wheels, crankcases, |
| valve systems, underbody parts, etc. |
|
| |
| |
| |
|
|
| Made-to-order blasting chamber are |
| manufactured according to the products to |
| be blasted. A dust collector is selected at |
| the same time depending on the air volume |
| and the ventilation in the chambers. |
| In consideration of the circulation collection |
| of the injected media, we will provide advice |
| on the method of collection either by an |
| operator for low costs or automated |
| collection. |
|
| |
|
| For silicon wafers and quartz boards |
| |
|
| For the approximate five-inch wafers, one to |
| six wafers can be processed simultaneously. |
| The front loading type provides loading/ |
| unloading of products from the same position, |
| which result in space savings. In addition, |
| a through type conveyor type is also available. |
| A special device to stably inject fine powder |
| is equipped as standard. L/S = 50/50_m |
| can be supported depending on the masking. |
| The variation ranges from a testing type for |
| a single wafer in a 100 mm_100 mm size to |
| a continuous processing type. In addition, |
| a blasting machine to remove the leathery |
| condition on quartz ingots is also available. |
|
| |
| |
| |
|
|
| The cabinet is selectable for product shape |
| and weight among the general types. |
| Nozzles attachment/detachment of product |
| are fully automated using robots. Various |
| products can be supported by adding memory |
| and external storage units in the robot. The |
| robot can be combined with any type of |
| machines. A variety of work can be supported |
| by teaching the robots. |
|
| |
|
| For semiconductors and electronic parts |
| |
|
| For high-precision processing industry |
| including semiconductors, a mechanism that |
| injects fine powder ofa few_mwith stability, |
| rate, and particle size is controlled at the |
| same time for patterning, drilling and roughing |
| of printed circuit boards. A cyclone for |
| seperation and a dust collector also have fine |
| powder-specific types. |
|
| |
| |
| |
|
|
